Vertix® Systems. Engineered for life

EasySeam® Metal Wall Cladding System

EasySeam Metal Wall Cladding System is currently available as a standard build up.

Wall System with Green Labels and Purple Background

Why Choose EasySeam® Wall Cladding System?

Arrow

Standard Build-Up

The EasySeam wall profile is supported by and fixed to an 18mm Oriented Strand Board (OSB) 3 and a breathable membrane. This construction build up will achieve a Class C in the European Fire test ISO 9705-1:2016 and is suitable for use on some low-rise buildings (less than 11 metres high in England) and further than 1 metre from the boundary.

Arrow

Key features of EasySeam® Wall Cladding System

EasySeam Wall Cladding System uses a metal standing seam profile to offer a robust and durable solution that’s quick and easy to install. Offered as a complete system EasySeam Wall Cladding System includes breather membrane, corner and window flashings, fixings and sealant, ensuring you get the very best aesthetics and quality for your walling project.

Have any questions?

Contact Us
Tick

Engineered system that’s manufactured to order, reducing on site waste.

Tick

3 different EasySeam® profiles, each with a 25mm high seam.

Tick

Available in a choice of pre-finished steel options and colours depending on building application; SSAB Greencoat® Pural and Tata Steel Colorcoat HPS200 Ultra® and Colorcoat Prisma®.

Tick

Available in 300mm and 500mm widths.

Tick

Up to 8 metre lengths available.

Tick

Profiles can be laid horizontally or vertically to achieve different aesthetic effects.

Tick

Snap and lock system enables quick and easy installation.

Tick

Fixings are hidden by the adjacent profile, delivering a stylish and sleek appearance

Tick

CE marked to EN14783.

Tick

Also available in a soffit plank.

EasySeam® Wall Cladding System Profiles

Arrow

Discover our profile range

EasySeam Wall Cladding System is available in 3 different profiles and also a Soffit Board to suit different aesthetic requirements.

Vertix Systems provides a range of different materials and finishing options
Material Options

Depending on building application, available in Tata Steel Colorcoat® and SSAB GreenCoat® pre-finished steel options.

View material options

    • EasySeam Flat Profile EasySeam flat profile drawing

    EasySeam® Flat Profile

    Available in 2 widths 500mm and 300mm.
    • EasySeam Pencil Profile EasySeam single pencil profile drawing

    EasySeam® Single Pencil Profile

    Available in 300mm and 500mm width profiles with a central 2mm upstand.
    • EasySeam Narrow Rib Profile EasySeam Narrow rib profile drawing

    EasySeam® Narrow Rib Profile

    Available in 300mm and 500mm width profiles with a 25mm central rib.
    • Soffit profile for walls

    EasySeam® Soffit Plank

    Can be used as wall cladding laid horizontally or vertically. Available in widths up to 350mm.

Confidex® Home

Arrow

Free 25 Year Confidex® Home Guarantee

For individual residential dwellings or homes, we exclusively supply Tata Steel Colorcoat® branded products; Colorcoat Prisma® and Colorcoat HPS200 Ultra®.  When used as part of a standing seam roof or wall cladding system for residential dwellings or homes in the UK and Ireland, both products benefit from the free 25 year Confidex® Home Guarantee issued directly to the homeowner by Tata Steel. In the unlikely event of a coating failure, Tata Steel can be contacted directly, meaning a prompt response in the event of a claim.



Please note soffits and fascias are excluded from Confidex® Home Guarantee.

Download Files

Brochures

Dropdown Arrow

Vertix EasySeam® Roof and Wall Systems

Roof and Wall Systems

Colour Cards

Dropdown Arrow

Colorcoat Prisma® by Tata Steel

Roof and Wall Systems

Colorcoat HPS200 Ultra® by Tata Steel

Roof and Wall Systems

SSAB GreenCoat® Colour Card

Roof and Wall Systems

Profile Drawings

Dropdown Arrow

Vertix EasySeam® Narrow Rib Profile Drawing

Roof and Wall Systems

Vertix EasySeam® Flat Profile Drawing

Roof and Wall Systems

Vertix EasySeam® Soffit Plank Detail

Roof and Wall Systems

Vertix EasySeam® Single Pencil Profile Drawing

Roof and Wall Systems

Sustainability Data

Dropdown Arrow

Colorcoat Prisma® by Tata Steel EPD

Fire Insulation

Colorcoat HPS200 Ultra® by Tata Steel EPD

Roof and Wall Systems

SSAB GreenCoat® EPD

Roof and Wall Systems

What sort of guarantee is available for Vertix EasySeam® Wall Cladding System?

The primary guarantee is provided by the material supplier.



Depending on application, Tata Steel Colorcoat® branded products (Colorcoat Prisma® and Colorcoat HPS200 Ultra®) are available with either the Confidex® Guarantee (for industrial and commercial projects) or Confidex® Home Guarantee. This is the market leading pre-finished steel guarantee.



SSAB offers a more general guarantee with their pre-finished steel products.



Depending on the location and application, good quality pre-finished steel products can have a 50 year life span.  Tata Steel talks about period to repaint decision, which effectively means if the steel roof is repainted at specified intervals (usually every 25 years or more) it should last forever.



A workmanship guarantee is available from the installer and Vertix® Systems recommends customers asking for an insurance backed guarantee. Alternatively, you can get a latent defect insurance policy for the whole building. NHBC or Premier are providers of such insurance policies.

What is the Colour Range for Vertix EasySeam Wall Cladding System?

This depends on the material source.

Vertix Systems can supply Tata Steel Colorcoat HPS200 Ultra® in Anthracite Matt and Colorcoat Prisma® in Anthracite, with a choice of colours from the standard colour card available on request.

Vertix Systems can supply SSAB GreenCoat® Pural BT in Slate Grey Matt, Stone Grey Matt and Nordic Black. A choice of alternative colours from the standard colour card are available on request.

You can find Colorcoat HPS200 Ultra®, Colorcoat Prisma® and GreenCoat® Pural colour cards on our downloads page.

How do I get a price for Vertix EasySeam Wall Cladding System?

Complete the online price enquiry form and we will provide a speedy response catered to your individual requirement.  To complete this you will require details of the roof type and dimensions. Alternatively, there is an option on the price request form to attach drawings and any additional specific requirements for the project and submit these to our sales team who will respond with a complete estimate price.

How is Vertix EasySeam Wall Cladding System packed and delivered to site?

The panels are sized to the length of your roof rafter plus fascia.  Any trims and other fabrications such as eave flashings and soffits are supplied in 3 metre lengths.

Wall Cladding panels are packed in length and these will not necessarily be the full height of the elevation due to deflection requirements.

All panels are packed and delivered to site in a crate providing protection, and covered with polythene to minimise water ingress.

What is the lead time for Vertix EasySeam Wall Cladding System?

The lead time quoted ranges from 2-8 weeks, depending on your individual colour requirement and our on-hand stock availability.

However, it should be noted there is high demand on installation contractors and therefore early engagement is recommended circa 6 months to avoid delays in the commencement of your project. The chosen installer will be able to manage the lead time and order placement with Vertix Systems, generally by placing a reservation order.  Vertix Systems will purchase the material specified for your project to meet the required delivery time to site.

When the wall is ready to be measured for the final order, it is typically 4 weeks from placement of order or payment to delivery to site.

How do you start and finish Vertix EasySeam Wall Cladding System to ensure it has a neat finish?

It is important to mark the layout of the wall prior to installation. You will need to make a starter and end panel to suit the wall. For windows on a wall, 100mm of EasySeam profile will need to fall outside of the window.

What comes in the EasySeam Wall Cladding System kit of parts Vertix® Systems can supply?

Vertix EasySeam Wall Cladding System kit of parts includes:-

  • EasySeam standing seam profiles or soffit planks
  • Breather membrane if relevant to the project
  • Bottom of the wall detail flashings
  • Window detail flashings
  • Corner of the wall and top of the wall trim flashings
  • Fixings

Can profiles manufactured by Vertix Systems for soffits be used on walls?

Yes, the Soffit plank Vertix Systems manufactures can also be used on a wall either vertically or horizontally.
